RF Beacon 3
product

RF Beacon 3 is a compact single‑band RF beacon operating in the 868 MHz band. Designed as a reliable synchronization and control source, it offers streamlined timing and trigger functionality for professional audio‑visual, broadcast, and event environments.

Key Benefits

  1. Optimized Single‑band Performance
    Focused 868 MHz operation provides extended range and stable signal penetration, ideal for environments requiring predictable wireless coverage without multi‑band complexity.
  2. Audio and Timecode Synchronization
    RF Beacon 3 distributes audio and linear timecode (LTC) signals with high precision, ensuring consistent frame‑accurate timing across cameras, playback, and lighting systems.
  3. Integrated Local Signaling
    A built‑in buzzer and a single GPIO interface allow basic system feedback, alerts, or trigger outputs — making RF Beacon 3 well‑suited for compact synchronization or control setups.
  4. Professional‑grade Reliability
    Engineered for studio, broadcast, and live‑event use, RF Beacon 3 delivers robust, interference‑resistant performance and consistent timing even in challenging RF environments

Interfaces and Connectivity

Building on its streamlined architecture, RF Beacon 3 offers the essential wired interfaces required for dependable beacon operation.

Interface / Feature Function Typical Use
868 MHz RF Band Long‑range wireless link using proprietary low‑band protocol Reliable beaconing or control in large venues and complex environments
Audio Input (Line‑level) Accepts analog audio signals Wireless audio cue distribution or audio‑synchronized beaconing
GPIO / Trigger I/O (×1) Single configurable digital input/output pin External trigger or status indication within connected systems
Buzzer (Local Alert) Built‑in acoustic indicator Audible confirmation or event signaling on site
USB Port (LTC Input - Linear Timecode)

Power interface

Receives SMPTE‑compatible linear  timecode

 Provides a single LTC signal input. Frame‑accurate synchronization for cameras, recorders, and playback systems
Status Indicators LED and visual status feedback

Immediate confirmation of mode and operation

Note:
RF Beacon 3 supports over‑the‑air (OTA) firmware updates; the USB port is intended for device configuration, and power only.

All interfaces can operate simultaneously within defined configuration profiles.

Applications

RF Beacon 3 is suited to professional AV workflows where dependable timecode and control beaconing are needed, but wireless requirements remain straightforward.

Broadcast and Film Production

Provides frame‑accurate timecode and audio distribution between cameras, recorders, and playback systems where a dedicated 868 MHz RF link offers interference‑free performance.

Live Events and Stage Control

Offers reliable RF triggering for lighting, playback, or effects systems in venues where simplicity and robustness are priorities.

Studios and Fixed Installations

Acts as a synchronization hub for permanent setups, distributing timecode or reference audio to connected equipment over a compact wireless link.

Training, Presentations, and Demonstrations

Enables synchronized playback or control cues for classroom, showroom, or demonstration environments where precise timing between devices matters, but Bluetooth® or infrared features are unnecessary.

Summary

With its focused single‑band radio design and essential interface set, RF Beacon 3 provides a simple yet dependable solution for wireless synchronization and control. It brings RF Beacon‑series timing accuracy and reliability to cost‑sensitive or compact installations without requiring multi‑protocol complexity.
